Navori Labs proudly presents StiX 3800, an industry-first digital signage player featuring AI-driven audience analytics. Despite a decade of technological advancement, there is still room for improvement in player devices in the industry.
Enhancing industry solutions to ensure that all user messages are displayed effectively on screens while also developing key performance indicators that accurately reflect audience engagement and screen exposure time is essential.
The StiX 3800 uses Navori’s professional native player, offering up to eight times better performance than the industry standard web player. It also has the power reserve to support new features and more advanced content over time.
StiX 3800 is available through major distributors in your region or directly from Navori via our subsidiaries in America, Europe, the Middle East, and Asia. Contact us!
All-in-One Digital Signage Player
Top Performance and Versatility
The StiX 3800 features the latest processors and GPU, enabling seamless 4K@60fps playback. The Navori app allows broadcasting across synchronized media players, with API support for on-demand content triggering and third-party hardware interaction. Rest assured of its reliable and high-quality performance.
AI Audience Analytics
StiX 3800 is a pioneering media player featuring an AI-driven VPU for unparalleled audience insights. Beyond basic metrics, it tracks dwell and screen exposure time, offering comprehensive analytics via the Navori CMS. Effortlessly analyze audience behavior and screen performance with real-time data feeds from the micro camera, enabling dynamic content personalization.
Seamless Screen Monitoring
StiX 3800’s intuitive software allows you to effortlessly handle power, sources, and technical aspects. Leverage the Navori CMS for remote display control, ensuring maximum uptime and adaptability. Stay ahead with fluid screen monitoring, guaranteeing peak performance from anywhere.
Certified for Continuous Security
The Navori StiX 3800 is FCC, CE, and BIS certified, ensuring it safeguards against new threats. Navori CMS remotely updates both the Android operating system and Navori player software, keeping the device current with the latest features and security patches. Additionally, it is GDPR compliant, respecting user privacy and data security across various regions.
Impressive 170° Detection,
8 Meters Around the Screen!
The StiX 3800 features AI-driven body-shape counting and dwell time tracking, offering detailed audience analytics. The data collected can be linked to the media displayed, providing insights over specific periods, days of the week, or even specific hours.
With a 170° detection angle, the micro camera covers up to 8 meters around the screen, effectively capturing data from both standing and seated individuals. Importantly, this feature complies with the strictest privacy regulations, as it does not collect age or gender data.
Power over Ethernet
Bid farewell to the hassle of external power supplies as the StiX 3800 draws power directly through the Ethernet cable, simplifying your setup.
Hands-Free Setup
The device automatically downloads and displays content without any technical setup. Just connect the network cable and discreetly place the compact device behind the screen for effortless control over your digital signage.
Screen and Player Device Inventory Management
The StiX 3800 stays connected to the screen, ensuring smooth tracking while retrieving internal parameters like settings, temperature, and component status. This data is sent to the CMS for analysis and triggers alerts if necessary, providing real-time insights into player devices and screens.
Sustainability with StiX 3800
Digital Signage Player
The StiX 3800 provides multiple green features to support companies’ energy-saving efforts.
Energy Efficient
StiX 3800 consumes around 80% less electricity compared to a PC used for digital signage.
Eco-Aware Viewer Detection
The device utilizes a micro camera to detect viewer presence within an 8-meter range. If no viewers are detected, the Navori app automatically switches off the screen.
Customized Operating Hours
Navori Labs’ CMS allows for customized operating hours for each screen, potentially doubling its lifespan and reducing electricity consumption by nearly half.
Green Setup Solution
The hands-free setup removes the need for on-site technician visits, reducing travel and lowering carbon emissions, making it a more sustainable solution.
Built To Last
The StiX 3800 is designed for industrial operation, boasting a lifespan of up to 50,000 hours. This exceptional durability not only ensures reliability but also contributes to long-term sustainability, with the device capable of lasting for 9 years when used for 15 hours daily, seven days a week, throughout the year.
Product | StiX 3800 |
Chip Model | Rockchip RK3568 |
CPU | Quad-core Cortex-A55 |
GPU | Mali-G52 |
RAM | 4GB |
Storage | Internal 16GB (11GB Available for content storage) + Micro SD Slot, Class 10 SD Card of up to 128 GB |
Dimensions | L :115.3mm W: 80mm H: 28mm L: 4.53 in W: 3.14 in H: 1.10 in |
LAN / WAN
(Power over Ethernet) |
X2 RJ45 Interfaces First Ethernet Supports PoE |
Wifi | IEEE 802.11b/g/n/ac (2.4G&5G ) |
Operating System | Android 11 |
Product | StiX 3800 Micro Camera |
Model | UC-501-2MP-D170 |
Sensor | CMOS 1/2.7” 2MP |
Resolution | 1920*1080P@30FPS |
Output | USB2.0,USB-A |
FOV | D170° H147° wide angle |
Photo Format | MJPG |
Video Output | MJPG/YUY2 |
Dimensions | 15*15mm |
Length of Cable | 2M |
Power | 5V / 90mA |
Material | Plastic camera with metal lens |
Temperature | -10~+70℃ |
Can I use an external power module to power the equipment if PoE is unavailable?
The Navori client portal allows you to order a power module compatible with North America, Europe, and the UK.
How do I adjust the camera positioning?
From the CMS, you can activate a mode that displays the camera’s video feed on
part of the screen. This allows you to verify that the detection of body shapes or
vehicles is working correctly.
Can I use a camera other than the one offered by Navori?
Yes, the camera must be Android-compatible.
Can the camera be connected post-deployment?
Yes, as soon as the camera is connected, it is automatically detected, and data
collection is activated automatically.
Is the StiX 3800 delivered with an HDMI cable?
It is delivered without an HDMI cable. The connection is female.
Can I use an IP camera with the StiX 3800?
IP camera support needs to be planned, as the goal is to measure the audience of
a screen.
How do I set up control and monitoring of my screens?
Connect an Ethernet cable between the StiX 3800 and your screen. The software
will automatically detect the screen. It is recommended that the Navori CMS
mobile app be used to test power on/off during installation. See the list of
compatible brands on the Navori website.
Is screen control via CEC still functional?
Yes, but the StiX 3800’s functionalities will be limited to turning the screens on
and off.
Can the storage capacity of the StiX 3800 be extended?
Yes, the StiX includes a Class 10 Micro SD card slot.
How do I configure the auto-activation of the StiX 3800?
1. From your client access, specify 1. the URL of your CMS.
2. Please select a player license from the CMS and assign it to a StiX 3800.
Does the Navori Player software need to be reactivated after a firmware update?
Reactivating Navori player is unnecessary; the process is optimized to avoid onsite intervention.
How do firmware security updates work?
Navori makes a new firmware version available to the CMS at regular intervals.
The user can specify if and when each unit should be updated. The process is
applied by default at night when the screens are turned off.
DooH Programmatic Advertising
Maximize your return on investment (ROI) by leveraging precise campaign management and real-time optimizations with the StiX 3800, ensuring your programmatic advertising efforts are highly effective.
Social Media and KPI Dashboards
Use Navori connectors to display live Social Media Walls and KPI dashboards in your retail space, providing real-time stats for your employees and social media activity.
Digital Menu Boards
The StiX 3800 ensures perfect multi-screen synchronization for digital menu boards and retail media networks. Showcase new products, deals, or menu inventory by integrating with your POS system. Enhancing visibility and customer interaction in busy retail or dining environments.
Control at Your Fingertips with Navori Mobile
Ideal for retail, digital menu boards, and public venues. Navori Mobile companion app for managing digital signage content from your mobile device. It allows you to take control by updating playlists, launch media, and modify schedules, adjust volume and displays in real-time. Perfect for dynamic environments.
